AfterVLX 100 Arched / Custom Door in Hialeah, FL | TruePane Windows & Doors
The VLX 100 Arched / Custom Door is what happens when a manufacturer decides a front entry should look like architecture, not an afterthought. Every unit is CNC-bent from structural aluminum into a true radius curve, so the arch flows without seams, kinks, or filler strips. In Hialeah, where mid-century ranches sit next to new Mediterranean builds, that kind of curved entry changes the whole face of a home. TruePane Windows & Doors is an authorized ViewLux installation partner, which means you’re getting factory-matched product knowledge plus local install crews who set these doors level, plumb, and square. Call (386) 977-5410 to talk through your arched opening.
Product Overview - VLX 100 Arched / Custom Door
The VLX 100 exists for one reason: builders and homeowners in Hialeah kept asking for a curved aluminum entry door that did not look like a compromise. The arch is fabricated on CNC bending equipment, so the radius is exact, repeatable, and structurally honest. There is no field-bent guesswork, no caulk-packed miter joints. The extrusion profile measures 2.56 inches wide with a wall thickness of 0.098 inches, which gives the frame real torsional stiffness while still reading as a sleek architectural line.
Where this door fits best is any elevation where a flat header would flatten the design. Think arched porch openings in the Country Club section, fountain-court entries off East 4th Avenue, or a custom radius carved into a modern box-form house near Amelia Earhart Park. Buyers choose the VLX 100 because it holds a true arch shape under South Florida thermal cycling, which is exactly where lighter vinyl or wood arched units start to creep, bind, or sag. And because every unit is fabricated to order, the span is not limited to some catalog maximum. If your rough opening is a true radius, TruePane Windows & Doors can have ViewLux fabricate to that exact dimension. That is the difference between a door that fits and a door that looks like it was forced. Call (386) 977-5410 for details on current fabrication lead times.
Technical Specifications
The build sheet reads like a door meant for Hialeah’s worst August afternoon. Here is what goes into every VLX 100 Arched / Custom Door TruePane orders:
- Frame profile width: 2.56″ extruded aluminum with thermal break
- Wall thickness: 0.098″ on the primary extrusion
- Span capability: Custom fabricated to the measured radius and rough opening width; no standard-size ceiling
- Fabrication method: CNC-bent arch, single continuous radius, no segmented miter joints
- Glass options: Clear, Frosted, Obscure, Low-E, Tempered, Laminated
- Finish options: Premium Black, Pure White, Anodized Silver, Bronze, Champagne, Teak Wood
- Impact option: Laminated impact-resistant glazing for wind-borne debris zones
- Performance compliance: NFRC-rated energy values, AAMA 2400/2410 installation standard, AAMA 812 perimeter sealant system
TruePane Windows & Doors orders every VLX 100 to the job site measurement, not off a shelf. That matters more on an arched unit than on any rectangle.
Performance Features
Thermal Efficiency - The VLX 100 carries a polyamide thermal break between the interior and exterior aluminum faces. That break interrupts the heat path that would otherwise bake the inside of a Hialeah entry in July. NFRC-rated performance means you’re not guessing at the U-factor; the number is real and verifiable.
Acoustic Performance - Aluminum frames with a true thermal break also damp sound better than non-broken extrusions. On a busy Hialeah street, that means traffic noise and motorcycle exhaust stay outside where they belong. The tighter the perimeter seal, the better the STC performance, and this frame is sealed to AAMA 812 spec.
Airtightness & Weather Seal - Every perimeter joint on a VLX 100 installed by TruePane gets low-expansion AAMA 812 foam sealant, not generic hardware-store caulk. That is the standard for real aluminum fenestration. It moves with the frame through thermal cycles instead of cracking away after two seasons of Hialeah sun.
Waterproofing - The arch shape itself helps shed water, but gravity is not a weather seal. The sill, jamb flashings, and header cap are all detailed so that driving rain from a typical South Florida afternoon storm drains out and away, never into the rough opening. Mist prevention at the glass line comes from the triple-barrier seal design on the glazing pocket.
Wind Resistance - Hialeah sits inside the High Velocity Hurricane Zone map. The VLX 100 is wind-load rated for that requirement, and when ordered with laminated impact glass, it meets impact protection provisions. That means no accordion shutter needed across a statement arched entry.
Security & Hardware - The VLX 100 accepts multi-point locking hardware and heavy-duty hinges rated for the weight of a fully glazed arched leaf. Aluminum this thick resists pry attacks far better than thin residential extrusions, and the laminated glass option makes forced entry through the lite genuinely difficult.
Color & Glass Options
Finish selection on an arched door is not just color preference. It is context. Premium Black reads sharp against white stucco and coral-stone trim, which is a dominant Hialeah palette. Pure White blends into Spanish-revival facades and art deco multi-family entries. Anodized Silver is the quietest option for modern concrete box homes, and it will not chalk under UV exposure like a painted finish eventually can.
Bronze and Champagne are warmer metallics that pair with terracotta roof tile and natural wood doors elsewhere on the property. Teak Wood is a woodgrain-effect finish that gives the texture of a timber entry without rot, warp, or termite exposure, which is a real consideration in Hialeah’s humidity.
On the glass side, Clear is for entries where you want the door to disappear. Frosted and Obscure let light through while blocking the sightline into the foyer. Low-E is the pick for west-facing arches that catch the full afternoon sun. Tempered glass is the safety baseline for full-lite doors. And Laminated impact glass is the option that satisfies hurricane protection without changing the look of the door. Tell TruePane which direction your entry faces when you call (386) 977-5410, and we will point you to the right glass for that exposure.
Installation by TruePane Windows & Doors in Hialeah
An arched aluminum door is only as good as the rough opening it goes into, and that is where we earn our keep. TruePane Windows & Doors installs every VLX 100 to AAMA 2400/2410, which is the recognized installation standard for this class of product. The process starts before the old door comes out. We check the rough opening for plumb, level, and square at the header, both jambs, and the sill. If the opening is out of square, we correct the framing before the new arched unit arrives, because you cannot shim a CNC-bent radius back into shape. You lower a warped opening onto it instead, and the door will tell you it is unhappy within a year.
During installation, the frame is set level, plumb, and square against a measured reference plane, not by eye. Shims are placed at every anchor point, and each anchor is set into framing, not into stucco or trim. The perimeter gets low-expansion AAMA 812 foam sealant on all four sides, including the arched head. That foam does two jobs: it air-seals the gap and it provides a secondary water barrier behind the exterior flashing. Then the exterior perimeter receives the proper flashing and cladding detail so water from a Hialeah downpour is directed away from the opening.
After the door is hung and glazed, we run a water test on the sill and lower arch. If there is a leak path, it shows up in our test, not in your first storm. We then cycle the door, set the hardware, and clean the job. The manufacturer’s warranty on the VLX 100 assumes a proper install. An arched door set by someone who does not understand radius geometry voids that warranty fast. TruePane installs these doors the way ViewLux expects them installed, so the warranty stays intact. Call (386) 977-5410 to schedule a rough opening inspection before you order.
Frequently Asked Questions - VLX 100 Arched / Custom Door
Lead time for a custom arched VLX 100 varies by fabrication queue and finish selection, but a realistic window for a Hialeah order is roughly 4 to 8 weeks from field-measured approval to delivery. The measurement happens first, then fabrication, then installation. Call (386) 977-5410 and we will give you the current build schedule straight from the partner line.
The VLX 100 can qualify for energy-efficiency incentives when ordered with Low-E glass and the thermal break package, but eligibility depends on the specific NFRC performance values for your configuration. Energy credits are not automatic on a door with clear glass. Ask TruePane for the NFRC numbers on your chosen glass package and give those to your tax preparer.
The VLX 100 carries ViewLux’s manufacturer warranty on the frame, finish, and glazing, and that warranty stays valid because TruePane Windows & Doors installs to the manufacturer’s required standard. Labor coverage, glass breakage, and finish warranty terms differ by product line. Call (386) 977-5410 for the exact warranty language on your configuration.
Yes. The VLX 100 Arched / Custom Door is fabricated to order, which means the width, height, radius, and jamb depth are all matched to your measured rough opening. There is no standard-size limitation. If your Hialeah home has a true radius arch that is unusual, we measure it and order to that shape, not the closest catalog approximation.
Wash the frame with mild soap and water twice a year, rinse thoroughly, and keep the sill track clear of debris. Avoid abrasive cleaners and pressure washers aimed at the glazing seals. In Hialeah’s salt-adjacent air, anodized finishes hold up better with that simple rinse schedule. Call (386) 977-5410 if you ever see sealant separating or the door sticking in the frame; catching it early keeps the warranty clean.
Get a Quote - VLX 100 Arched / Custom Door in Hialeah
You will not price an arched entry like this on a website form, and that is a good thing. Every VLX 100 is built to a measured opening, so the quote should be too. Call TruePane Windows & Doors at (386) 977-5410 to schedule a free on-site measurement and get a written line-item quote for your arched door project in Hialeah. We will walk the rough opening with you, confirm the radius, and spec the glass and finish that fit your home. Free estimate, no change orders, fixed pricing.
Written by the team at TruePane Windows & Doors, authorized ViewLux installation partner serving Hialeah and surrounding Miami-Dade neighborhoods since opening our doors.
